This filter has a hinged top plenum which provides easy access to the top removal style filter cartridges. The filter media is a Spun Bonded Filter Cartridge with 45 pleats per element. No support cage is required.
STANDARD FEATURES
Clean air plenum with clean air outlet stub
Jet pulse cleaning complete with:
Compressed air header and diaphragm valves
Internal air piping
Adjustable pulse timer board and solenoids mounted in a NEMA 4 enclosure
Spun bonded polyester cartridge media with 45 pleats per element
Magnehelic differential pressure gauge with filter
Flanged mounting connection
OPTIONAL FEATURES
Available in carbon steel or stainless steel construction
NEMA 4X or NEMA 7/9 timer enclosure
Industrial/Food grade epoxy interior
Smooth not Flush (80 grit) or Smooth and Flush (120 grit) weld seams
Flanged product inlet/clean air outlet
Pulse on demand differential pressure gauge and/or switch
