This cyclone utilizes centrifugal force to separate particles from the air. The air exhausts out the top and the particles are discharged out the bottom.
STANDARD FEATURES
Carbon steel or stainless steel construction
Slope top design to enhance product/air separation
80 degree cone with flanged product discharge
Draw through exhaust fitting
Standard support lugs (support by buyer)
OPTIONAL FEATURES
Support legs/structure
Inspection/Access opening
Industrial/Food grade epoxy interior
Smooth not Flush (80 grit) or Smooth and Flush (120 grit) weld seams
